20W Track Light Built-in

Product Description

• Cylinder and compact size with in-track driver adapter, passive cooling system ensures the long life of luminaires.
• Deep anti-glare structure with visual comfort lights in UGR<17. Exchangeable Lens and inner rings for friendly stock.
• Honeycomb and in-track TRIAC / 0-10V / DALI dimming optional. Dim to Warm and Tunable White available.

• Specification

  Overview

  Model	TL2501-20W
  Power	20W
  Beam Angle	15 °/24 °/36 °/50 °
  Driver	BOKE/LIFUD
  Installation	3-phase / 1-phase
  Dimension	Φ75 × L170mm
  CCT	2700K/3000K/3500K/4000K
  CRI	80Ra/90Ra
  Luminous Flux	2000lm
  LED	Origin Bridgelux COB
  Color	White / Black / Custom
  Surface finish	Powder Coating
  Material	Die Casting Aluminum
  IP Rate	IP20
  Input Voltage	AC220-240V
  Vf & If	30-42V 500mA

•
